DB ES503 Stereo
Sistema de som com 1000w de amplificação, pode ser usado como sistema stereo com subgrave + 2 satélites, como em Mono unindo os 2 satélites, sugrave de 12”, cada top com 4x3”, misturador de 3 canais XLR/Jack Combo integrado, bluetooth, barra e cabo incluído.
Technical Data
Speaker Type 3-amped Stereo System with
two full-range tops and one subwoofer
Acoustical data
Frequency Response [-10dB]37 - 15.000 Hz
Max SPL121 dB
MF - HF8x 3"
Type MF - HFNeodymium
LF12"
Directivity95x65°
Amplifier
Amp TechnologyDigipro® G3
Amp ClassClass-D
Power Amp Peak1000 W
Processor
ControllerDSP 24 Bit/48 kHz
System PresetsFactory presets + User defined
LimiterDual Active, Peak, RMS, Thermal
Crossover Frequency LF-HF206 Hz
Input
Mic/Instrument Channel1x Combo (XLR/Jack) balanced/unbalanced input
Line Channels2x Combo (XLR/Jack) balanced/unbalanced inputs
Media Channel1x Bluetooth® built-in receiver
Mix Output1x XLR balanced output
Mechanics
Housing (Subwoofer)15mm Black Painted Plywood
Housing (Tops)Polypropylene PP
Handles2x lateral side (Subwoofer)
Width (Top)95 mm (3.74 in)
Height (Top)360 mm (13.98 in)
Depth (Top)137 mm (5.39 in)
Width (Subwoofer)465 mm (18.3 in)
Height (Subwoofer)400 mm (15.7 in)
Depth (Subwoofer)430 mm (16.9 in)
Weight (Top)1.9Kg – 4.19lbs.
Weight (Subwoofer)16.4Kg – 36.16lbs.
